Description
The Cisco C9200-48P-E Switches is the Catalyst 9200 48-port PoE+ Switch, with Network Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise. It is secure, always-on, and IT simplified.
| Product Description | Cisco Catalyst 9200 - Essential Edition - switch - 48 ports - smart - rack-mountable |
| Device Type | Switch - 48 ports - smart - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 740 W |
| Performance | Wireless bandwidth: up to 48 Gbps ? Switching capacity: 176 Gbps ? Forwarding rate: 261.9 Mpps |
| Capacity | Virtual networks: 4 ? MAC addresses: 32000 ? IPv4 routes: 14000 ? Indirect IPv4 routes: 4000 ? Direct IPv4 routes: 10000 ? IPv4 routing table entries: 4000 ? IPv6 routing table entries: 2000 ? Multicast scale: 1000 ? ACL scale entries: 16000 ? Packet buffer size: 6 MB ? Flexible NetFlow entries: 16000 ? VLAN IDs: 1000 |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocol | OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Remote Management Protocol | NETCONF, RESTCONF |
| Features | Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Flexible NetFlow (FNF), MACsec support, Control plane protection (CoPP), Sampled NetFlow, Switched Port Analyzer (SPAN), Embedded Event Manager (EEM), First Hop Security (FHS), DNA support |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
| Power | AC 120/230 V |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 44.5 cm x 4.4 cm x 35 cm |
| Weight | 5.5 kg |
| System Requirements | Cisco IOS XE 16.9.2 or later |
| Manufacturer Warranty | Limited lifetime warranty |
